Image Sensor |
Type |
CMOS |
Sensor Size |
23.5 x 15.7 mm |
Effective Pixel |
Approx 20.3 |
Total Pixel |
Approx 21.6 |
Colour Filter |
RGB Primary Color Filter |
Lens Mount |
Mount |
Samsung NX Mount |
Usable Lens |
Samsung NX Lenses |
Image Stabilization |
Type |
Lens Shift (depends on Lens) |
Mode |
OIS Mode1 / Mode2 / OFF |
Distortion Correct |
LDC On / Off (Depends on Lens) |
i-Function |
i-Depth, i-Zoom (x1.2, 1.4, 1.7, 2.0), i-Contrast |
Display |
Type |
Super AMOLED with Touch Panel (C-Type Touch Control Enabled) and Swivel (Horizontal : 180degree, Vertical : 270degree) |
Size |
76.7mm (3.0") |
Resolution |
FVGA (720x480) 1037k dots (S-Stripe) |
Field of View |
Approx 100 |
Guide Display |
Yes |
ViewFinder |
Type |
Tiltable EVF w/ Eye Contact Sensor |
Resolution |
XGA (1024 x 768) 2,359K dots |
Filed of View |
Approx 100 |
Magnification |
Approx. 0.96x (Equivalent to a 50mm lens) |
Eyepoint |
Approx. 18.5 |
Diopter Adjustment |
Approx. -4.0 ~ +1.0 |
Focusing |
Type |
Hybrid AF (Phase & Contrast) |
Focusing point |
Total AF Point : 105points (Phase Detection AF), 247points (Contrast AF), Selection : 1point ( Free selection ), Multi : Normal 21(3x7)points, Closeup 35points, Face Detection : Max. 10 faces |
Mode |
Single AF, Continuous AF, MF, Touch AF&Shutter |
AF-Assist Lamp |
Yes |
Shutter |
Speed |
Auto:1/8000sec. ~ 1/4sec. (EFS available), Manual:1/8000sec. ~ 30sec. (1/3EV step) (EFS available), Bulb ( Limit time : 4min. ) |
Exposure |
Metering System |
TTL 221(17x13) Block segment, Metering : Multi, Center-weighted, Spot, Metering range : EV -3 ~ 18 (ISO 100 · 30mm, F2) |
Compensation |
±3 EV (1/3EV step) |
AE Lock |
AEL Button |
ISO Equivalent |
Auto, 100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600 (1 or 1/3EV step), AUTO ISO upper level is selectable. (Up to ISO3200) |
Drive Mode |
Mode |
Single, Continuous, Burst (5M size only), Self-timer, Bracket (AE/WB/PW/Depth) |
Continuous |
JPEG : High(9fps) , Normal(4fps) selectable, Burst : 10, 15, 30fps selectable , RAW : High(9fps), Normal(4fps) selectable |
Bracket |
Auto Exposure Bracket (±3EV), WB, PW, Depth |
Self-Timer |
2 - 30 sec (1 sec Step) |
Flash |
Type |
A-TTL Pop-up flash |
Mode |
Smart Flash, Auto, Auto+Red-eye reduction, Fill-in, Fill-in+Red-eye reduction, 1st Curtain, 2nd Curtain, Off |
Guide Number |
11 (at ISO 100) |
Angle of View Coverage |
28mm Wide-Angle (Equivalent to 35mm) |
Sync Speed |
Less than 1/200 |
Flash Compensation |
-2 - +2 EV (0.5 EV step) |
External Flash |
Samsung External Flash available |
Synchro (Flash attachment) |
Hot Shoe |
White Balance |
Micro Adjustment |
Each 7 Steps in Amber / Blue / Green / Magenta Axis |
Mode |
Auto, Daylight, Cloudy, Fluorescent (W, N, D), Tungsten, Flash, Custom, K(Manual) |
Dynamic Range Expansion |
Off / Smart Range+ / HDR |
Effect |
Picture Wizard |
Standard, Vivid, Portrait, Landscape, Forest, Retro, Cool, Calm, Classic, Custom (1~3) |
Smart Filter |
Vignetting, Minature, Colored Pencil, Watercolor, Wash Drawing, Oil Sketch, Ink Sketch, Acryl, Negative, Selective Color (R/G/B/Y 4 Colors) |
Still |
Mode |
Smart Auto, Program, Aperture Priority, Shutter Priority, Manual, Custom1, Custom 2, Lens Priority, Smart, Wi-Fi |
Smart |
Beauty Face, Landscape, Macro, Action Freeze, Rich Tone, Panorama, Waterfall, Silhouette, Sunset, Night, Fireworks, Light Trace, Creative Shot, Best Face, Multi-Exposure, Smart Jump Shot |
Image Size |
JPEG (3:2):20.0M (5472x3648), 10.1M (3888x2592), 5.9M (2976x1984), 2.0M (1728x1152), 5.0M (2736x1824): Burst mode only, JPEG (16:9):16.9M (5472x3080), 7.8M (3712x2088), 4.9M (2944x1656), 2.1M (1920x1080), JPEG (1:1):13.3M (3648x3648), 7.0M (2640x2640), 4.0M (2000x2000), 1.1M (1024x1024), RAW : 20.0M (5472x3648), * 3D mode with 3D lens is available only with JPEG (16:9) 4.1M (2688x1512) or 2.1M (1920x1080) |
Quality |
Super fine , Fine, Normal |
Colour Space |
sRGB / Adobe RGB |
Video |
Format |
MP4 (H.264) |
Compression |
Movie: H.264 / Sound: AAC |
Mode |
Program, Aperture Priority, Shutter Priority, Manual |
Image Size |
1920x1080, 1920x810, 1280x720 , 640x480, 320x240(for Sharing) |
Frame Rate |
60fps, 30fps, 24fps(1920x810 Only), (* 3D - 30fps Only) |
Multi-Motion Recording |
x0.25 (640, 320 only), x0.5 (1280, 640, 320 only), x5, x10, x20 |
Quality |
High Quality , Normal |
Sound |
Stereo Sound (w/ Input Level Adjustment, Audio Level Display) |
Image Play |
Type |
Single image, Thumbnails (15/24 images), Slide show, Movie |
Edit |
Still |
Smart Filter, Red-eye fix, Resize, Rotate, Face Retouch, Brightness, Contrast |
Movie |
Still Image Capture / Time Trimming |
Memory |
External Media |
SD, SDHC, SDXC, UHS-1 Support |
Capacity (2GB) |
20.0M : RAW 57 20.0M (3:2) : Super Fine 150, Fine 180, Normal 224 10.1M (3:2) : Super Fine 271, Fine 325, Normal 405 5.9M (3:2) : Super Fine 411, Fine 492, Normal 613 2.0M (3:2) : Super Fine 797, Fine 952, Normal 1180 Burst (5.0M) : Super Fine 464, Fine 555, Normal 690 16.9M (16:9) : Super Fine 174, Fine 209, Normal 261 7.8M (16:9) : Super Fine 335, Fine 401, Normal 499 4.9M (16:9) : Super Fine 471, Fine 564, Normal 701 2.1M (16:9) : Super Fine 781, Fine 933, Normal 1158 13.3M (1:1) : Super Fine 214, Fine 257, Normal 321 7.0M (1:1) : Super Fine 363, Fine 435, Normal 542 4.0M (1:1) : Super Fine 538, Fine 643, Normal 800 1.1M (1:1) : Super Fine 1030, Fine 1227, Normal 1519 Movie : 1920x1080 60p: High Quality 10m 10s, Normal 12m 43s 1920x1080 30p : High Quality 17m 41s, Normal 22m 9s 1920x810 24p : High Quality 21m 35s, Normal 27m 02s 1280x720 60p :High Quality 16m 51s, Normal 21m 6s 1280x720 30p : High Quality 29m 11s, Normal 36m 35s 640x480 30p : High Quality 120m 47s, Normal 153m 30s 320x240 30p : High Quality 218m 48s, Normal 278m 24s ※ These figures are measure under the Samsung standard. |
Languages |
Languages |
30 Languages (Korean, English, Danish, German, Dutch, Swedish, Spanish, Italian, Czech, French, Portuguese(Portugal), Portuguese(Brazil), Polish, Finnish, Russian, Norsk, Simplified/Traditional Chinese, Arabic, Persian, Turkish, Hebrew, Thai, Greek, Hungarian, Estonian, Lithuanian, Latvian, Serbian, Croatian) |
Network and Wireless Connectivity |
Wi-Fi |
IEEE 802.11b/g/n support Dual Channel (Smart Camera 3.0) . AutoShare . SNS & Cloud . Email . Auto Backup . Remote Viewfinder Pro . Mobile Link . Samsung Link . Group Share . Photo Beam . HomeSync . Baby Monitor |
NFC |
Yes |
Interface |
Digital Output Connector |
USB 2.0 (micro USB Jack) |
Video Out |
NTSC, PAL, HDMI 1.4a |
External Release |
Yes |
Battery |
Capacity |
Rechargeable battery : BP1410 (1410mAh, 7.6V) |
Charging |
DC 5.0V, 1A via Micro USB port |
Still Image Capturing Time |
180 min / 360 shots (CIPA Standard) |
Physical specification |
Dimension (WxHxD) |
127 x 95.5 x 41.7 |
Weight |
375g |
Operating Environment |
Operating Temperature |
0 - 40 |
Operating Humidity |
5 - 85 |
Software |
Application |
Adobe Photoshop Lightroom 5, iLauncher |
System Requirement |
Windows |
Intel i5 3.3GHz or Higher AMD Phenom II x4 3.2GHz or higher Minimum 512MB RAM (1GB or more recommended) Windows 7 / 8 250MB of available hard-disk space (1GB and above recommend) USB 2.0 port CD-ROM drive nVIDIA Geforce 7600GT or higher / ATI X1600 series or higher 1024×768 pixels, 16-bit color display compatible monitor (1280x1024, 32-bit color display recommended) Microsoft DirectX 9.0c or later |
Macintosh |
Mac OS 10.5 or higher (except PowerPC) Minimum 256MB RAM (512MB or more recommended) Minimum 110MB of available hard-disk space USB 2.0 port CD-ROM drive |
