| CAMERA |
| Image Sensor |
Super35mm type CMOS |
| System |
RGB primary colour filter (Bayer array) |
| Total Pixel |
9.84 megapixels |
| Effective Pixels |
8.29 megapixels |
| Minimum Illumination |
NTSC Mode 0.3 Lux
[F1.2 lens , 24 dB, 29.97P mode, shutter speed 1/30]
PAL Mode 0.25 Lux
[F1.2 lens, 24 dB, 25.00P mode, shutter speed 1/25] |
| Sensitivity |
NTSC: F9
[1920x1080/59.94i , ISO640 (0dB), 2000 Lux, 89.9 percent reflection]
PAL: F10
[1920x1080/50.00i , ISO640 (0dB) , 2000 Lux, 89.9 percent reflection] |
| S/N Ratio |
NTSC: 54dB (Typical)
[1920x1080/29.97P, Canon Log base sensitivity ISO850 (Dynamic range 800 percent )]
PAL: 54dB (Typical)
[1920x1080/25.00P, Canon Log base sensitivity ISO850 (Dynamic range 800 percent )] |
| Dynamic Range |
During normal shooting: 300 percent
With Canon Log gamma: 800 percent
(ISO 850 or above/gain 2.5 dB or more) |
| Horizontal Resolution |
Up to 1000 TV lines or more (1920 x 1080i mode), depends on lens used |
| Lens Mount |
Canon EF Mount |
| Focal length |
Equivalent to 1.53x the focal length of EF lenses;
As indicated for EF-S lenses and Canon cine lenses |
| Peripheral Illumination Correction |
YES (dependent on lens used) |
| ND filter |
3 glass filters in camera body: 2 stops; 4 stops; 6 stops. Operate via body or wireless control |
| Focus control |
Via lens, wireless control or wired remote (dependent on lens used) |
| Iris control |
Via body, grip, wireless control or wired remote
1/2-stop, 1/3-stop or FINE control
Possible to maintain constant F-number during zoom |
| Image Stabilization System |
Depends on lens used |
| Image Processor |
DIGIC DV III |
| RECORDING |
| Video Storage Media |
Type 1 Compact Flash memory cards (2 card slots) |
| Type |
UDMA4, 30MB/s or faster (40MB/s or faster for Fast/Slow recording) |
| Recording Time |
64GB CF card: Up to 160mins (1080/50i @ 50 Mbps) |
| Recording File Format |
Material eXchange Format (MXF); OP-1a pattern |
| Recording Format |
MPEG-2 Long GOP
50Mbps CBR (4:2:2) MPEG-2 422@PHL;
35Mbps VBR (4:2:0) MPEG-2 MP@HL;
25Mbps CBR (4:2:0) MPEG-2 MP@H14 |
| Recording Frame Rate |
50Mbps: 1920 x 1080/59.94i, 50i, 29.97p, 25p, 24.00p, 23.98p;
1280 x 720/59.94p, 50p, 29.97p, 25p, 24.00p, 23.98p.
35Mbps: 1920 x 1080/59.94i, 50i, 29.97p, 25p, 23.98p;
1280 x 720/59.94p, 50p, 29.97p, 25p, 23.98p.
25Mbps: 1440 x 1080/59.94i, 50i, 29.97p, 25p, 23.98p. |
| Slow/Fast Motion |
YES
720p: 1-60fps in 1fps steps
1080p: 1-30fps in 1fps steps
(available options may differ according to recording mode selected) |
| Interval Record |
YES. 1, 2, 3, 6, 9 or 12 frames, 25 time intervals
(available options may differ according to recording mode selected) |
| Frame Record |
YES. 1, 2, 3, 6, 9 or 12 frames
(available options may differ according to recording mode selected) |
| Pre Record (cache record) |
YES (3 seconds) |
| Relay Recording |
YES |
| Double Slot (simultaneous) Recording |
YES |
| Scan Reverse |
YES. Up/down, left/right, up/down/left/right image inversion |
| HD-SD conversion |
NO |
| Internal Data Transfer |
MOVIE: Yes (CF card to CF card) |
| Photo Storage Media |
SD/SDHC memory card |
| Still Quality |
During video recording: 1920 x 1080;
During playback: 1920x1080, 1280 x 720 |
| SYSTEM |
| LCD Size |
10.1 cm (4"), 100 percent view |
| Dots |
1.23 million |
| Image Quality Adjustments |
Brightness, contrast, colour, sharpness, backlight, black & white |
| Adjustable |
Up/down/left/right according to camera configuration |
| Waveform Monitor |
Waveform Monitor and Vectorscope |
| Focus Assist |
Peaking; Magnifying; Edge Monitor (using waveform display) |
| Image Quality Adjustments |
Brightness, contrast, colour, sharpness, backlight, black & white |
| Adjustable |
Vertical tilt |
| Audio Iin |
XLR inputs with 48V phantom power (x2), 3.5mm microphone input jack |
| Headphone Output |
3.5mm stereo jack |
| Video Monitor Output |
YES (BNC, SD output only via Synch terminal) |
| HDMI |
YES (Type A, output only) |
| HD/SD-SDI Output |
YES (BNC, output only, embedded audio and time code) |
| Time code |
YES (BNC, switchable input/output) |
| Genlock |
YES (BNC, input only) |
| Synch |
YES (BNC, output only, 5 modes: HD Sync, HD-Y, SD blackburst, SD composite, Off) |
| Remote Control Terminal |
2.5mm mini jack |
| Wireless Control Terminal |
YES (optional accessory required for wireless control) |
| Tally lamp |
Yes |
| Accessory Shoe |
YES (cold shoe, 3 locations: top of body, top of handle, front of handle) |
| Custom key |
YES (15 assignable buttons; select from 30 functions) |
| SHOOTING FUNCTION |
| Exposure Metering |
Manual exposure determined by shutter setting, iris setting, ISO/gain setting and ND filter setting |
| ISO Sensitivity |
1-stop display: 320, 400, 800, [850]², 1600, 3200, 6400, 12800, 20000
1/3rd stop display: 320, 400, 500, 640, 800, [850]², 1000, 1250, 1600, 2000, 2500, 3200, 4000, 5000, 6400, 8000, 10000, 12800, 16000, 20000 |
| Gain Setting |
NORMAL: -6dB, -3dB, 0dB, 3dB, 6dB, 9dB, 12dB, 15dB, 18dB, 21dB, 24dB, 30dB;
FINE: 0 dB to 24 dB (0.5 dB increments) |
| Shutter Speed |
1/3 to 1/2000 depending on frame rate and Shutter Control Mode |
| Control Modes |
Off; Speed; Angle; Clear Scan (CS); Slow Shutter (SLS) |
| Shutter Angle |
11.25 degree to 360 degree depending on frame rate |
| Slow Shutter (SLS) |
1/3, 1/4, 1/6, 1/8, 1/12, 1/15, 1/25, 1/30 depending on frame rate |
| Clear Scan |
59.94i/p: 59.94 - 250.27Hz;
50i/p: 50 to 250.78Hz;
29.97p: 29.97 - 250.27Hz;
25p: 25 to 250.78Hz;
23.98/24p: 23.98 - 250.27Hz |
| Stored Configurations |
9, including 2 presets (CINEMA and EOS Std) |
| Storage Medium |
SD/SDHC memory card (all customisation data and metadata), up to 20 Custom Pictures per card |
| Gamma |
8 profiles |
| Master Pedestal |
-50 to +50 |
| Master Black |
-50 to +50 for each of R,G,B |
| Black Gamma |
Adjustable Level, Range and Point |
| Low Key Saturation |
-50 to +50 adjusts colour saturation in low brightness area |
| Sharpness |
Adjustment for Level, H Detail Freq., Coring, HV Detail Balance, Limit, Select, Knee Aperture and Level dependent sharpness |
| White Balance |
-50 to +50 white balance offset for R,G,B |
| Colour Correction |
Area selection / area revision of two areas |
| Setup Level |
-50 to +50 On/Off |
| Preset |
Daylight (5400K), Tungsten (3200K), Kelvin (2000K-15000K, 100K intervals), Set A, Set B |
| White Balance Shift |
YES. -9 to +9 (Daylight and Tungsten only) |
| Countup System |
Regen, RecRun, FreeRun, External, Hold (Drop frame available for some frame rates) |
| Audio Recording |
16-bit 2ch (48 kHz) linear PCM |
| Control |
Independent limiters and auto/manual settings |
| Microphone Attenuation |
Yes |
| Microphone Level Meter |
Yes |
| ACCESSORIES |
| Supplied |
XF Utility and NLE Plug-ins, Monitor Unit (LCD and XLR), Handle Unit, Thumbrest, Tripod base adaptor plate, Shoulder strap, Eyecup, EVF cap, Battery Charger CG-940, Compact power adapter CA-940, Battery pack BP-955 |
| Optional |
Batteries BP-955, BP-975, Compact Power Adaptor CA-930 (battery charger only), Tripod Adapter TA-100, Wireless Controller WFT-E6 |
| Battery Power Consumption |
10.3W (NTSC mode)
10.0W (PAL mode) |
| Continuous Recording Time |
Supplied BP-955: Approx. 205 minutes
Optional BP-975: Approx. 310 minutes |
| MISCELLANEOUS |
| Dimensions |
Approx 133 x 179 x 171mm (thumbrest attached);
Approx 174 x 179 x 171mm (grip attached);
Approx 185 x 284 x 301mm (grip, monitor unit and handle attached) |
| Detachable Handle |
YES |
| Weight |
1430g |
| Operating Temperature Range |
-5 degree C to +45 degree C, 60 percent relative humidity |
