Standards | IEEE802.3ab 1000Base-T IEEE802.3z 1000Base-SX |
Supported Frame Size | Standard Ethernet up to 10Kbytes |
Network Media | 1000Base-TX: Cat. 6 EIA/TIA-568 100-ohm UPT/STP, up to 100m 1000Base-SX: Multi-mode fiber optic cable 50/125 µm, up to 550m |
Protocol | CSMA/CD |
Ports | 1 x 1000Base-T 1 x 1000Base-SX (SC-type) |
Dip Switch | Fiber (forced/auto-negotation) LLR (enable/disable) |
Transfer Rate | 2000Mbps (full-duplex) |
Media | MMF |
Power | 7.5V DC, 1A external power adapter |
Power Consumption | 2.7 Watts |
Certification | FCC, CE |
Temperature | Operating: 0 Degree ~ 40 Degree C (32 Degree ~ 104 Degree F) Storage: -25 Degree ~ 70 Degree C (-13 Degree ~ 158 Degree F) |
Humidity | Max. 90 Percent (non-condensing) |
Dimension | 120 x 88 x 25mm |
Weight | 354g |
