| Standards |
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n (up to 300Mbps)
IEEE 802.11ac (up to 867Mbps)
|
| Hardware Interface |
USB 2.0
LED Indicator
|
| Special Features |
High-speed 802.11ac connectivity
Explicit Beamforming
Supports MU-MIMO technology
|
| Compatibility |
Windows 10, 8.1, 8, 7
Mac OS 10.9 – 10.12
|
| Data Rate |
802.11a: up to 54Mbps
802.11b: up to 11Mbps
802.11g: up to 54Mbps
802.11n: up to 300Mbps (2.4GHz & 5GHz)
802.11ac: up to 867Mbps
|
| Encryption |
64/128-bit WEP, WPA / WPA2-Enterprise, WPA / WPA2-PSK (AES/TKIP) |
| Quality of Service |
WMM |
| Frequency |
2.400 – 2.483GHz
5.150 – 5.825GHz
|
| Modulation |
802.11b: CCK, DQPSK, DBPSK
802.11a/g: OFDM with BPSK, QPSK and 16/64-QAM
802.11n: BPSK, QPSK, 16-QAM, 64-QAM with OFDM
802.11ac: OFDM with BPSK, QPSK and 16/64/256-QAM
|
| Antenna |
2.4GHz / 5GHz: 2 x 1 dBi (max.) dual band internal |
| Output Power |
802.11a: 8.5 dBm (max.) @ 54Mbps
802.11b: 9.5 dBm (max.) @ 11Mbps
802.11g: 8.5 dBm (max.) @ 54Mbps
802.11n: 7.5 dBm (max.) (2.4GHz & 5GHz) @ 300Mbps
802.11ac: 5.5 dBm (max.) @ 867Mbps
|
| Receiving Sensitivity |
802.11a: -70 dBm (typical) @ 54Mbps
802.11b: -81 dBm (typical) @ 11Mbps
802.11g: -70 dBm (typical) @ 54Mbps
802.11n (2.4GHz): -68 dBm (typical) @ 300Mbps
802.11n (5GHz): -67 dBm (typical) @ 300Mbps
802.11ac: -54 dBm (typical) @ 867Mbps
|
| Wireless Channels |
2.4GHz: FCC: 1-11; ETSI: 1-13
5GHz: FCC: 36, 40, 44, 48, 149, 153, 157, 161, 165; ETSI: 36, 40, 44, 48, (52, 56, 60, 64, 100, 104, 108, 112, 116, 132, 136, 140)**
|
| Power |
Consumption: Max. 0.98W |
| Operating Temperature |
0° – 40° C (32° – 104° F) |
| Operating Humidity |
Max. 90% non-condensing |
| Dimensions |
20 x 15 x 7mm (0.8 x 0.6 x 0.3 in.) |
| Weight |
2g (0.07 oz.) |
