Technology |
Projection System |
3LCD Technology, RGB liquid crystal shutter |
LCD Panel |
0.59 inch with C2 Fine |
Image |
Colour Light Output |
3,200 Lumen- 1,900 Lumen (economy) |
White Light Output |
3,200 Lumen- 1,900 Lumen (economy) |
Resolution |
WXGA, 1280 x 800, 16:10 |
Aspect Ratio |
16:10 |
Contrast Ratio |
10,000 : 1 |
Light source |
Lamp |
Lamp |
214 W, 4,000 h durability, 7,000 h durability (economy mode) |
Keystone Correction |
Auto vertical: ± 30 °, Manual horizontal ± 20 ° |
Colour Processing |
10 Bits |
2D Vertical Refresh Rate |
100 Hz - 120 Hz |
Colour Reproduction |
up to 1.07 billion colours |
Optical |
Projection Ratio |
1.04 - 1.26:1 |
Zoom |
Manual, Factor: 1 - 1.2 |
Image Size |
30 inches - 300 inches |
Projection Distance Wide/Tele |
1.35 m - 1.62 m ( 60 inch screen) |
Projection Lens F Number |
1.58 - 1.7 |
Focal Distance |
13.52 mm - 16.22 mm |
Focus |
Motorized |
Offset |
10 : 1 |
Connectivity |
USB Display Function |
3 in 1: Image / Mouse / Sound |
Interfaces |
USB 2.0 Type A, USB 2.0 Type B, VGA in, HDMI in, Composite in, Stereo mini jack audio in, Miracast, MHL, Near Field Communication (NFC), Wireless LAN IEEE 802.11b/g/n, Wireless LAN b/g/n (2.4GHz) |
Epson iProjection App |
Ad-Hoc / Infrastructure |
Advanced Features |
Security |
Kensington lock, Wireless LAN security, Password protection |
2D Colour Modes |
Dynamic, Cinema, Presentation, sRGB, Blackboard, DICOM SIM |
Features |
AV mute slide, Built-in speaker, Document Camera Compatible, Fit to Screen, Gesture Presenter, Home Screen, Instant on/off, JPEG Viewer, Long lamp life, MHL audio/video interface, PC Free, iProjection App for Chromebook, Quick Corner, Screen Mirroring, Split-Screen-Function, Wireless LAN capable, iProjection App |
Video Colour Modes |
Blackboard, Cinema, Dynamic, Presentation, sRGB, DICOM SIM |
Genreal |
Energy Use |
295 Watt, 208 Watt (economy), 0.34 Watt (standby) |
Supply Voltage |
AC 100 V - 240 V, 50 Hz - 60 Hz |
Product dimensions |
292 x 213 x 44 mm (Width x Depth x Height) |
Product weight |
1.8 kg |
Noise Level |
Normal: 39 dB (A) - Economy: 30 dB (A) |
Temperature |
Operation 5° C - 40° C, Storage -10° C - 60° C |
Humidity |
Operation 20% - 80%, Storage 10% - 90% |
Options |
Document camera |
Loudspeaker |
1 Watt |
What's in the box |
Carrying Case, VGA cable, Power cable, Remote control incl. batteries, Software (CD) |
