| Video |
8CH |
| System |
NTSC/ PAL (Auto Detection) |
| Compression |
H.264 |
| Input |
Cat5 (RJ45 x 8) |
| Output |
Video Out (RCA) x 1, VGA x 1 |
| Display Frame Rate |
240/200 fps |
| Display Resolution |
720 x 480/ 720 x 576 (NTCS/ PAL), VGA: 1280 x 1024 |
| Display Mode |
1/4/Sequence/PIP |
| Audio |
| Audio In/ Out |
1/1 |
| Recording/ Playback |
| Recording Resolution (NTSC/ PAL) |
D1: 720x480 / 720x576, Half D1: 720x288 / 720x240, CIF:
360x240 / 360x288 |
| Recording Rate (NTSC/ PAL) |
D1: 60/50 fps Half D1:120/100 fps CIF: 2400/200 fps |
| Recording Mode |
Time (Continuous) / Motion Detection / Sensor / Motion &
Sensor |
| Playback |
Search by Time / Event / Calendar |
| Sensor/ Alarm |
| Sensor/ Alarm |
8 / 4(Optional) |
| Storage/ Backup |
| Storage Support |
SATA HDD x 1 |
| Backup Device |
USB Stick |
| Connector |
| USB |
USB 2.0 Port x 1 |
| Mouse |
USB Mouse Port x 1 |
| IR Extender |
IR Jack and Cable (Optional) |
| OSD/ Control |
| GUI/ Control Interface |
YES / Mouse, Keypad, IR Remote Controller(Optional) |
| Multilingual Menu |
Yes |
| Access Authentication |
Yes |
| Digital Zoom |
Yes, 1x~8x, Both in Live Mode & Playback Mode |
| PIP |
Yes, On/Off |
| Channel Swap |
Yes, via Mouse Drag-and-Drop |
| PTZ Control |
Yes, RS485, Via Mouse or Keyboard |
| Firmware Upgrade |
USB/ Network |
| Network |
| Network |
10/100 Ethernet (RJ-45) |
| Network Protocol |
TCP/IP, Static IP, DHCP, PPPoE(ADSL),DDNS |
| Network Remote |
Client Program and IE Browser |
| Multilingual OSD |
Yes |
| 3G Mobile Viewing |
Yes |
| E-mail Notification |
Yes |
| Other Info |
| Power Supply |
Input: AC100~240V 50/60Hz, Output: DC12V |
| Operating Temperature |
5°C~45°C |
| Dimension (WxHxD cm) |
21.4 x 4.4 x 23.7 cm |
| 1/3” CCD 10m IR Camera |
| System |
NTSC/EIA; PAL/CCIR |
Pick-up Device
|
1/3” SONY CCD |
Active Picture Elements
|
NTSC: 1028(H) x 508(V) / PAL: 1028(H) x 598(V) |
Signal Processing
|
Digital (DSP) |
Synchronization System
|
Internal |
Gamma Correct
|
0.45 |
Minimum Illumination
|
IR LED Off: 0.04Lux (F1.6AGC On, 50 IRE); IR LED On:0 Lux |
Horizontal Resolution
|
700 TV Line (Color) |
Mounting Method
|
Provided Bracket On Top Or Bottom |
Day/Night Switching
|
Automatic Switch To B&W Signal Output at 1.0 Lux by Light
Sensor Control |
Window Screen
|
Coated Optical Glass |
Illumination
|
12 x 850mm LEDs |
Illumination Distance
|
Approx. 15m |
| Sunshield |
Included |
| Dimension |
Refer To Drawing |
| Automatic Shutter Control |
NTSC 1/60 ~ 1/10Ks; PAL:1/50~100Ks |
| Gamma Correction |
0.45 |
| Automatic Shutter Control |
Yes |
| Signal-To-Noise Ratio |
More Than 48dB |
| Aperture Correction (APC) |
Horizontal And Vertical |
| Intergrated Lens |
6mm F2.0, 3.6mm 4.3mm, 8mm, 12mm |
| Horizontal View Angle |
40~50 Degree (6mm and 8mm); 50 Degree (4.3mm) |
| Video Output |
1Vp-p CVBS, 75ohm, BNC |
| External Connections |
Video (BNC), DC 12V |
| Supply Voltage |
DC 12V |
| Power Consumption |
4.8W (Max.) |
| working Temperature |
-10oC ~ +50oC |
| Housing |
Alloyed Aluminum |
| Color |
Silver / Iron-Grey |
| Protection Standard |
IP66 |
| 1/3” CCD Dome Camera |
| System |
NTSC/ PAL |
| Pick-up Device |
1/3" Inter-Line Transfer CCD |
| Active Picture Elements |
NTSC: 510 (H) x 492 (V)/ PAL: 500 (H) x 582 (V) |
| Synchronization System |
Internal |
| Gmma Correct |
0.45 |
| Minimum Illumination |
0.1 Lux F1.2 |
| Horizontal Resolution |
420 TV Line (Color) |
| White Balance |
Auto Trace White Balance (2500K~9500K) |
| Electric Shutter |
Auto:NTSC 1/60 ~ 1/10K s: PAL: 1/50 ~ 100Ks |
| S/N Ratio |
More Than 48 dB (AGC Off) |
| Lens |
3.7mm F2.0 |
| Auto Gain Control (AGC) |
Auto |
| Back Light Compensation (BLC) |
Auto |
| Video Output |
BNC Composite:1.0 Vp-p/ 75 Ohms |
| Operation Temperature |
-10oC ~ +50oC |
| Powe Consumption |
2.2W Max |
| Current |
100mA (Max) DC 12V |
| Material |
Plastic |
| Color |
Beige |
