TECHNOLOGY |
Projection System |
3LCD Technology, RGB liquid crystal shutter |
LCD Panel |
0.63 inch with MLA (D7) |
OPTICAL |
Projection Ratio |
1.38 - 2.24:1 |
Zoom |
Manual, Factor: 1.6 |
Lens |
Optical |
Projection Size |
30 inches - 300 inches |
Projection Distance Wide/Tele |
1.69 m - 2.75 m (60 inch screen) |
Projection Lens F Number |
1.51 - 1.99 |
Focal Distance |
18.2 mm - 29.2 mm |
Focus |
Manual |
Offset |
8.6 : 1 |
IMAGE |
Colour Light Output |
3,500 Lumen-2,450 Lumen (economy) |
White Light Output |
3,500 Lumen - 2,450 Lumen (economy) In accordance with ISO 21118:2012 |
Resolution |
XGA, 1024 x 768, 4:3 |
Aspect Ratio |
4:3 |
Contrast Ratio |
10,000 : 1 |
Lamp |
200 W, 5,000 h durability, 10,000 h durability (economy mode) |
Keystone Correction |
Auto vertical: ± 30 °, Manual horizontal ± 30 ° |
Colour Processing |
10 Bits |
2D Vertical Refresh Rate |
50 Hz - 85 Hz |
Colour Reproduction |
Up to 1.07 billion colours |
CONNECTIVITY |
USB Display Function |
3 in 1: Image / Mouse / Sound |
Interfaces |
Microphone input, MHL, Ethernet interface (100 Base-TX / 10 Base-T), Stereo mini jack audio in (2x), Stereo mini jack audio out, RGB in (2x), S-Video in, Component in (2x), Composite in, HDMI in (2x), VGA out, VGA in (2x), Wireless LAN IEEE 802.11b/g/n (optional), RS-232C, USB 2.0 Type B, USB 2.0 Type A |
Epson iProjection App |
Ad-Hoc / Infrastructure |
ADVANCED FEATURES |
Security |
Kensington lock, Security cable hole, Wireless LAN unit lock, Wireless LAN security, Password protection |
3D |
- |
Features |
AV Mute Slide, Automatic keystone correction, Built-in speaker, Digital zoom, Direct Power on/off, Document Camera Compatible, Easy OSD pre-setting, Horizontal and vertical keystone correction, MHL audio/video interface, Network projection, OSD copy function, PC Free, Quick Corner, Split-Screen-Function, Wireless LAN capable, iProjecton set-up by QR code |
Video Colour Modes |
Blackboard, Dynamic, Presentation, sRGB, Theatre |
GENERAL |
Energy Use |
287 Watt, 215 Watt (economy), 0.26 Watt (standby) |
Supply Voltage |
AC 100 V - 240 V,50 Hz - 60 Hz |
Product Dimensions |
297 x 269 x 87 mm (Width x Depth x Height) |
Product Weight |
2.9 kg |
Noise Level |
Normal: 37 dB (A) - Economy: 29 dB (A) |
Temperature |
Operation 5° C - 35° C, Storage -10° C - 60° C |
Humidity |
Operation 20% - 80%, Storage 10% - 90% |
Included Software |
EasyMP Monitor, EasyMP Multi PC Projection, EasyMP Network Projection |
Options |
Document camera, Quick wireless USB key, Wireless LAN unit |
Loudspeaker |
16 Watt |
What's in the Box |
Carrying bag, Computer cable, Main unit, Power cable, Remote control incl. batteries |
