Technology |
Projection System |
3LCD Technology, RGB liquid crystal shutter |
LCD Panel |
0.63 inch with MLA (D7) |
Image |
Colour Light Output |
5,000 Lumen- 3,470 Lumen (economy) |
White Light Output |
5,000 Lumen - 3,470 Lumen (economy) |
Resolution |
XGA, 1024 x 768, 4:3 |
Aspect Ratio |
4:3 |
Contrast Ratio |
3,000 : 1 |
Lamp |
245 W, 2,500 h durability, 4,000 h durability (economy mode) |
Keystone Correction |
Auto vertical: ± 30 °, Auto horizontal ± 20 ° |
Colour Processing |
10 Bits |
Optical |
Projection Ratio |
1.38 - 2.24:1 |
Zoom |
Manual, Factor: 1 - 1.6 |
Image Size |
30 inches - 300 inches |
Projection Distance Wide/Tele |
0.8 m - 8.4 m/ 1.4 m - 13.9 m |
Projection Lens F Number |
1.51 - 1.99 |
Focal Distance |
18 mm - 29 mm |
Focus |
Manual |
Offset |
8.6 : 1 |
Connectivity |
USB Display Function |
3 in 1: Image / Mouse / Sound |
Interfaces |
Gigabit ethernet interface, Wired Network, DisplayPort, Composite in, VGA out, VGA in (2x), Wireless Network, RS-232C, Stereo mini jack audio in (2x), Stereo mini jack audio out, RGB out, RGB in (2x), HDMI in, USB 2.0 Type A, USB 2.0 Type B |
Advanced Features |
Security |
Kensington lock, Security bar, Control panel lock, Password lock |
Features |
AV mute slide, Automatic input selection, Automatic keystone correction, Direct Power on/off, Document Camera Compatible, Fit to Screen, Instant on/off, JPEG Viewer, PC Free, Quick Corner, Slide show, Split-Screen-Function |
Video Colour Modes |
Blackboard, Dynamic, Photo, Presentation, sRGB, Theatre, Whiteboard, DICOM SIM |
General |
Energy Use |
337 Watt, 250 Watt (economy), 0.44 Watt (standby) |
Supply Voltage |
AC 100 V - 240 V, 50 Hz - 60 Hz |
Product dimensions |
377 x 271 x 108 mm (Width x Depth x Height) |
Product weight |
3.9 kg |
Noise Level |
Normal: 37 dB (A) - Economy: 29 dB (A) |
Temperature |
Operation 5° C - 35° C, Storage -10° C - 60° C |
Humidity |
Operation 20% - 80%, Storage 10% - 90% |
Options |
Air filter |
Loudspeaker |
10 Watt |
What's in the box |
VGA cable, Power cable, Remote control incl. batteries, Software (CD), User manual, User manual (CD), Wireless LAN unit |
