Compatibility |
PC |
VGA to UXGA |
Mac |
VGA to SXGA+ |
Connector |
Digital |
HDMI 1.3 |
Audio Input |
3.5mm mini jack (x2) |
Audio Out |
3.5mm mini jack |
Network |
RJ-45 |
RGB Input |
15-pin mini D- sub (x2) |
Composite Input |
RCA jack |
S-Video Input |
4-pin mini-DIN |
RGB Output |
15-pin mini D- sub |
Control |
DB-9 |
USB |
Mini B (for mouse control and service) |
Power |
Voltage |
100 ~ 240VAC (Auto Switching), 50/60Hz (universal) |
Consumption |
310W (typ) <1W (stand-by mode) |
Controls |
Basic |
Power, keystone/arrow keys, left/blank, menu/exit, right/panel key lock, auto, mode/enter, source |
OSD |
Display: Screen color, Aspect Ratio, Keystone, Position, Phase, H. Size, Zoom, 3D Sync, 3D Sync Invert, Color Management Picture: Color Mode: PC (Brightest, PC, ViewMatch, Cinema, Dynamic PC, User 1, User 2), Video (Brightest, Gaming, ViewMatch, Cinema, Dynamic PC, User 1, User 2), Reference Mode: PC (Brightest, PC, ViewMatch, Cinema, Dynamic PC), Video (Brightest, Gaming, ViewMatch, Cinema, Dynamic PC), Brightness, Contrast, Color, Tint, Sharpness, Brilliant Color, Color Temp., Save Settings Source: Quick Auto Search, Color Space Conversion, ECOView, Timer, Smart Restart, Pattern, My Button System Setup (Basic): Language, Projector Position, Auto Power Off, Blank Timer, Panel Key Lock, Splash Screen, Screen Capture, Message, LAN Control Settings, Standby Settings (Active VGA Out / Active Audio Out) System Setup (Advanced): High Altitude Mode, DCR, Audio Settings (Mute / Volume), Menu Settings, Closed Caption, Lamp Settings, Presentation Timer (Timer Period, Timer Display, Timer Position, Timer Counting Direction, Sound Reminder), Security Settings, Remote Control Code, Reset All Settings Information: Current System Status (Source, Color mode, Resolution, Color System, Equivalent Lamp Hour, MAC Address) |
Operating Conditions |
Temperature |
32 F - 104 F (0 degree C - 40 degree C) |
Humidity |
10 percent - 90 percent (non-condensing) |
Altitude |
0~6,000 ft (1,800 m), operational up to 10,000 ft (3048 m) |
Display |
Type |
0.65" Digital Micromirror Device (DLP) |
Resolution |
WXGA 1280x800 (Native) |
Lens |
1.3x Manual optical zoom / Manual optical focus |
Keystone |
Vertical digital keystone correction, +/- 40 degree |
Display Size |
30" - 300" / 0.8 m - 7.6 m (Diagonal) |
Throw Distance |
3.9 ft - 32.8 ft / 1.2 m - 10 m |
Throw Ratio |
1.21 - 1.57:1 |
Lamp type |
240 watt |
Lamp life (normal/eco-mode) |
3,500 / 5,000 |
Data Path Protection |
ECC corrects up to 128 random bits/1KB |
Brightness |
3,500 Lumens |
Contrast Ratio |
15,000:1 (w/ DynamicEco) |
Aspect Ratio |
16:10 (native), 4:3, auto |
Color Wheel |
6-Seg RGBCYW / 7200RPM |
Color Gamut |
85 Percent NTSC 1931 CIE |
Color Depth |
30 bits, 1.07B Colors (10+10+10) |
Noise Level |
Normal |
33dB |
Eco-mode |
29dB |
Audio |
Speakers |
10W |
Input Signal |
Computer and Video |
NTSC M (3.58 MHz), 4.43MHz, PAL (B, D, G, H, I, M, N, 60), SECAM ( B, D, G, K, K1, L), SD 480i and 576i, ED 480p and 576p, HD 720p, 1080i and 1080p |
Frequency |
Fh: 31 -100KHz, Fv: 48 -120Hz |
Dimensions (W x H x D) |
Physical |
294 x 84 x 242 mm |
Packaging |
380 x 345 x 192 mm |
Weight |
Net |
2.6 kg |
Gross |
4.1 kg |
